CE & ISO Certified
Stainless Steel Frame
OEM / ODM Available
As a professional electric patient transfer chair supplier, Satcon Medical delivers the ST-77602 — a heavy-duty stainless steel patient lifter with a 180° split-seat design, dual-motor lifting, built-in commode, and 20-second tool-free folding. Designed for hospitals, elderly care facilities, and home care agencies worldwide. Whether you’re equipping a 200-bed rehabilitation center or building a private-label product line for the European home care market, this model bridges the gap between premium branded equipment and cost-effective OEM manufacturing — all from a single China-based factory with over a decade of medical device export experience.
✓ CE Certified
✓ ISO Standard
✓ OEM / ODM
46–72cm
Height Adjustment Range
27kg
Net Weight (Stainless Steel)
≥60cm
Door Width Compatible
Overview
Why Choose the ST-77602 as Your Next Electric Patient Transfer Chair?
For healthcare distributors and procurement managers sourcing a reliable electric patient transfer chair supplier, the ST-77602 addresses three critical pain points: reducing manual handling injury risk among nursing staff, ensuring compliance with international medical device import standards (CE / ISO), and delivering a product that works across diverse clinical environments — from narrow-doorway hospital rooms to low-clearance home care beds. Its stainless steel construction, dual-motor reliability, and tool-free portability make it a high-margin, low-complaint SKU for B2B portfolios.
As an experienced electric patient transfer chair supplier, the ST-77602 combines low maintenance costs with long-term durability. Its dual-motor system helps reduce servicing frequency, while the stainless steel frame performs reliably in humid and high-disinfection environments. Designed by a professional stainless steel electric patient lift factory, this model supports compliance with strict healthcare standards in Europe and other regulated markets. With competitive OEM pricing and low MOQ support, it delivers strong value for medical distributors and healthcare projects.
Core Features
Five Advantages That Set the ST-77602 Apart
As a professional electric patient transfer chair supplier, we designed the ST-77602 around one priority: safer patient transfers with reduced caregiver strain. From lifting stability to waterproof construction, every detail is built for daily clinical use. Below are the five key advantages that make this model stand out from traditional patient lifters and many standard OEM electric transfer chair China products on the market.
🔄
Flexible Moving
180° Split-Seat Transfer Design
The seat opens 180 degrees freely for seamless positioning around beds, wheelchairs, or commodes. No need to lift, hold, or manually move the elderly — the patient takes their seat independently. One nurse can complete the entire transfer operation without physical strain. This design is particularly valuable for post-surgical patients with limited mobility, bariatric patients requiring extra maneuvering space, and individuals who experience discomfort when being physically lifted by caregivers — preserving patient dignity while dramatically reducing musculoskeletal injury claims among nursing staff.
Compatibility: Door width ≥60cm · Underbed clearance ≥13cm · Bed height 45–70cm · Level ground
🔧
Dual Control System
Dual-Motor Electric Lifting with Remote
Dual-motor drive delivers more power, smoother motion, quieter operation, and longer service life compared to single-motor designs. Operators can lift via the control panel button or the wireless remote controller. The height range of 46–72cm covers most bed heights worldwide. Includes manual emergency descent for safety during power outages. The independent motor architecture also provides redundancy — if one motor experiences an issue during a lift, the second motor can safely support controlled descent to the lowest position, preventing patient suspension mid-air.
⏱️
Portable Storage
20-Second Tool-Free Disassembly
The foldable electric patient transfer chair disassembles in just 20 seconds without any tools. Quick-release mechanism means compact storage when not in use — ideal for facilities with limited space. Carton size 61×36×76.5 cm keeps shipping costs competitive for bulk orders. For distributors, this compact packaging translates to lower per-unit freight costs and higher container-loading efficiency — a meaningful advantage when importing 100+ units per shipment. Each carton also includes pre-assembled main frame components, reducing on-site setup time to under 5 minutes after unboxing.
🛡️
Durable Build
Heavy-Duty Stainless Steel Construction
As a specialized stainless steel electric patient lift factory, we use full stainless steel framing — not carbon steel with surface plating. This resists corrosion from daily alcohol or chlorine-based disinfection, withstands frequent use in humid care environments, including shower rooms and poolside transfer stations, and delivers a premium tactile feel that end-users and facility inspectors immediately notice. At only 27kg net weight, it’s lighter than most steel-frame competitors while maintaining superior structural rigidity. The material choice also means no rust-related warranty claims — a common pain point with carbon steel alternatives that develop oxidation at welded joints after 12–18 months of intensive use.
🪑
All-in-One Care
Built-in Commode & PU Leather Cushion
Comes standard with a built-in commode — combining toilet access and patient transfer in one device. The PU leather cushion is waterproof, easy to sanitize with standard hospital-grade disinfectants, and comfortable for extended sitting during rehabilitation sessions or meal times. Seat dimensions (46cm width × 40cm depth) accommodate most body types across Asian, European, and North American patient populations. Powered by a 24V / 2.6Ah lithium battery for long-lasting operation between charges — typically supporting 30+ lift cycles on a single charge under normal usage conditions.
Specifications
Technical Specifications — ST-77602
Complete technical data sheet for procurement documentation, customs declaration, and facility equipment specification files. All dimensions are measured in accordance with ISO 7176-19 wheelchair and mobility device testing standards.
| Item Number | ST-77602 |
| Frame Material | Stainless Steel |
| Seat Dimensions | Width 46cm × Depth 40cm |
| Seat Height Range | 46 – 72 cm (Electric Adjustment) |
| Max Loading Capacity | 100 kg |
| Net Weight | 27 kg |
| Wheel Size | Front 5″ / Rear 3″ |
| Motor System | Dual Motor (More Powerful & Quiet) |
| Battery | 24V / 2.6Ah Lithium Battery |
| Control Method | Control Panel Button + Wireless Remote Controller |
| Emergency Descent | Yes (Manual Safety Lowering) |
| Seat Material | PU Leather (Waterproof) |
| Built-in Accessory | Commode (Included) |
| Door Pass Width | ≥ 60 cm |
| Underbed Clearance Required | ≥ 13 cm |
| Bed Height Compatible | 45 – 70 cm |
| Certification | CE / ISO |
| Carton Size | 61 × 36 × 76.5 cm |
| OEM / ODM | Private Label, Custom Color, Packaging Available |
Applications
Ideal Applications for B2B Buyers
The ST-77602 is developed for hospitals, nursing homes, and medical distributors seeking a reliable electric patient transfer chair supplier with stable OEM support and long-term product consistency. Different buyers focus on different priorities — from bulk purchasing and compliance requirements to after-sales maintenance and resale margins. As a professional stainless steel electric patient lift factory, we help distributors match the right product positioning to their local healthcare market.
🏥
Hospitals & Rehabilitation Centers
Inter-room patient transfers, rehabilitation training assistance, ICU-to-general ward transitions, and post-operative mobility support. The 180° open design fits around hospital beds, imaging equipment (CT/MRI tables), and bedside monitors with minimal clearance required. Procurement teams in this segment typically prioritize CE certification documentation, warranty terms, and after-sales availability — all of which Satcon Medical provides as standard with every order. Average order quantity: 5–20 units per facility.
🏠
Elderly Care Facilities
Day-care centers, nursing homes, assisted living communities, and memory care units. Built-in commode eliminates separate toilet-transfer steps — a critical feature when residents require toileting assistance 3–5 times daily. Stainless steel frame withstands repeated disinfection protocols, including UV-C sterilization cycles common in modern eldercare facilities. Decision-makers in this segment often value ease of cleaning, noise level during nighttime transfers, and long-term durability over initial purchase price. Average order quantity: 10–30 units per facility.
👨👩👧
Home Care Agencies
Visiting nurses, home health aides, family caregivers, and hospice care providers. 27kg weight + quick-fold makes transport between client homes practical — fits in standard vehicle trunks or back seats without requiring a van or trailer. Remote control allows single-operator use even in confined spaces such as narrow hallways, small bathrooms, and compact bedrooms common in urban apartments. Home care agencies often operate on thin margins, so the combination of low initial investment and minimal maintenance requirements makes this model especially attractive for startups and regional service providers expanding their equipment fleet. Average order quantity: 2–10 units per agency.
Request ST-77602 Catalog or OEM Quote
Tell us your target market, required certifications, and annual volume — we’ll provide a competitive FOB quote and free sample for bulk orders over 10 units within 24 hours. Custom branding (logo placement on the control panel or frame), color options, and language-specific user manuals are available for OEM orders of 50+ units.
MOQ: 10 units · Lead time: 7–15 days · FOB Shenzhen / Tianjin · CE & ISO Certified
